Key Operational Functions & Features
- 6-Tray Loading Capacity: Dual-optimized to accommodate 6 standard pastry grids (600x400 mm) or Gastronorm GN 1/1 pans seamlessly.
- Smart Controlled Humidity (H₂O): Advanced direct steam and water injection profile to perfectly regulate moisture for crusty breads and delicate pastries.
- Auto-Reversing Ventilation Fan: Outfitted with smart reverse-gear fan alignment to eliminate internal chamber hot spots and distribute uniform heat.
- Precision Core Probe Cooking: Integrated internal cooking core probe (Sonda al Cuore) along with Delta T monitoring parameters for perfect meat roasting.
- Digital Programmable Recipes: Premium control board panel allows instant setup, saving, and recall of pre-programmed cooking recipes.
- Flexible Door Engineering: Equipped standard with a heavy-duty Left-Hinged door (Porta a bandiera SX), with an optional Right-Hinged configuration (Porta a bandiera DX) available on H₂O versions.
Technical Specifications
| Technical Parameter | Mastercool MID 6 Specification Value |
|---|---|
| Control Version Type | Electric - Digital Control Dashboard Panel |
| Tray / Loading Capacity | 6 Trays or Grids (600x400 mm or GN 1/1) |
| Distance Between Internal Trays | 80 mm |
| Inner Oven Chamber Size (WxDxH) | 680 mm x 480 mm x 520 mm |
| External Equipment Dimensions (WxDxH) | 840 mm x 920 mm x 835 mm |
| Total Electrical Power Input | 7.65 kW |
| Voltage Configuration | 220-240 V / 380-415 V 3/3+N (50/60 Hz) |
| Package Shipping Dimensions (WxDxH) | 880 mm x 955 mm x 980 mm |
| Net Weight / Gross Weight | 90 kg Net / 110 kg with Shipping Package |
Available Model Variant Codes
| Product Code | Technical Description Profiles |
|---|---|
| FEDL06NEMIDV | 6 Pans/Grids 600x400 mm or GN 1/1, WITHOUT H₂O injection, with water drain - Left Hinged Door |
| FEDL06NEMIDVH2O | 6 Pans/Grids 600x400 mm or GN 1/1, WITH H₂O injection and water drain - Left Hinged Door |
| FEDL06NEMIDVH2ODX | 6 Pans/Grids 600x400 mm or GN 1/1, WITH H₂O injection and water drain - Right Hinged Door (Optional) |
