Elevate your fresh product presentation while slashing operational energy costs with the Mastercool Vulcano VB Refrigerated Multideck Chiller. Engineered with authentic, high-quality Italian design and technology, the Vulcano VB variant features premium tempered glass hinged doors (Porte a Battente). These precision-built doors act as an absolute thermal barrier, maintaining strict climate conditions inside while stopping energy leaks. It is the ideal, space-saving vertical wall chassé merchandising solution for modern eco-conscious supermarkets, organic grocery channels, convenience stores, and butcher networks.
Key Features & Benefits
- High-Efficiency Hinged Doors: Built with robust, clear tempered glass hinged doors that sharply lower cold air migration, reducing electricity draw and overall strain on compressor hardware.
- Advanced Internal Illumination: Outfitted with specialized overhead LED lighting systems tailored specifically to enhance food color accuracy (White lighting for SL/FV configurations; Pink tinting for C fresh meat variants).
- Even Air Distribution: Backed by an intelligent electronic control panel and high-volume ventilated/forced-air dynamics to guarantee even temperature holding zones across all display layers.
- Flexible Merchandising Setup: Features non-toxic white-painted sheet metal or optional stainless steel adjustable shelving layers. Each tier comes standard with transparent price-tag rail scanner profiles.
- Eco-Responsible Performance: Uses advanced eco-friendly technical construction guidelines and is available with high-performance R290 green refrigerant gas infrastructure upon query.
Specialized Temperature Versions
- SL Variant (Dairy, Delicatessen & Drinks): Operates safely at +3°C to +5°C with 4 structural shelves. Engineered specifically for dairy items, pre-packaged cheeses, sandwiches, and beverages.
- FV Variant (Fruit & Vegetables): Operates evenly at +6°C to +8°C with 3 specialized inclined display shelves and an integrated upper tilted product mirror (Available for Vulcano VB 80).
- C Variant (Fresh Prepacked Meat): Operates at precision low ranges of 0°C to +2°C, complete with 4 reinforced shelves and an aerodynamic air deflector layout for maximum fresh food protection.
Technical Specifications
| Technical Parameter Element | Vulcano VB 60 Series | Vulcano VB 80 Series |
|---|---|---|
| Front Door Mechanics | Tempered Glass Hinged Doors (Porte a Battente) | Tempered Glass Hinged Doors (Porte a Battente) |
| Chassis Profile Depth | Compact Slimline 600 mm | High-Capacity Standard 765 mm |
| Chassis Baseline Height | 1984 mm (2080 mm structural height with wheels) | 2030 mm (2130 mm structural height with wheels) |
| Modular Width Sizes | Available layouts in 125 cm and 187 cm blocks | Available layouts in 125 cm, 187 cm, and 250 cm blocks |
| Side Wall Framing | Double-glazed insulated sides (Thickness: 40 mm per pane) | Double-glazed insulated sides (Thickness: 40 mm per pane) |
| Refrigeration Cooling Method | Ventilated / Dynamic Forced Air System | Ventilated / Dynamic Forced Air System |
| Eco-Gas Engineering | R290 / High-Efficiency Refrigerants Available | R290 / High-Efficiency Refrigerants Available |
| Standard Setup Accents | Pallet + Nylon protective delivery bundle packaging | Pallet + Nylon protective delivery bundle packaging |
